Wallboard LED Bar Light

Our slim and bright LED Bar Light is the perfect addition to any of our wall panels to create the perfect lighing environment for your frames!

See product specifications and sizes in the tabs below.

When purchasing this bar light, it comes with the transformer and mounting hardware to attach this to our wall panels.



Tech Specs

Tech Specs

• 21.5” Wallboard = 1700 Lm/ft 15W total (15” LED length)

• 29.5” Wallboard = 1700 Lm/ft 22.25W total (22.50” LED length)

• 37.5” Wallboard = 1700 Lm/ft 29.75W total (30” LED length)

• 45.5” Wallboard = 1700 Lm/ft 38.85W total (39” LED length)

- Minimum 90CRI
- CCT available: 2700K, 3000K, 3500K, 4000K, 4500K, 5000K
- Beam angle = 120°L x 90°W at lens aperture
- LED module rotates 324° total
- Lumen output programmable to 1,700 Lm/ft. max.
- Efficacy is 141.6Lm/W based on maximum output
- Flexible FR4 LED board construction with UL94V-0 rating
- Thermally engineered fixture housing constructed of heavy duty extruded aluminum
- Available with or without special diffusion film for optimum light distribution
- CSA listed
- Long electrical plug (9'3")
